Signing your emails with DKIM

It is advisable to set a DKIM record for your account. DKIM is Domain Key Identified Mail, a method for e-mail authentication that allows you to take responsibility for a message in a way that can be validated by a recipient. In other words, it allows the mail recipient to see that the message comes from you and not from us. Amongst others, Yahoo and Gmail check DKIM to filter out spam messages for their users.

Setting up DKIM keys requires domain access and system knowledge!

Step 1. Generate the DKIM key

The DKIM key is created in the Publisher

  • Under E-mailings, go to *Extra > *DKIM Keys.
  • In the dialog window, choose New DKIM key.
  • Enter your domain name (yourdomain.com) in the domain field.
  • In the subdomain field enter the name of the selector which will hold the DKIM key later on, without the ._domainkey part. In this example we use 'dkim' but you are completely free to use something else.
  • Choose the desired key strength. Note that large (e.g., 4096 bit) keys may not fit within a 512-byte DNS entry.
  • Store these settings.

Your key is now generated. The next step is to paste this key into the TXT record subdomain. You may close the DKIM dialog. The key remains available in the software.

Enter the information

Step 2. Paste the key into the TXT record on your subdomain

In step one, you have generated the key. The next step is to paste the key into the TXT record on your subdomain.

  • Sign in to the administrator console provided by your domain provider.
  • Locate the page from which you can update the DNS records.
  • Create a TXT record with the name dkim._domainkey. This includes the underscore. Underscores are allowed in certain DNS entries and actually required to make the DKIM work.
  • Paste the key provided in the marketing software value into the TXT record.
  • Save your changes. Once the DNS has been updated, the DKIM key can be sent along with your e-mails. This updating may take several hours.

The marketing software provides an extended DKIM validator to see if the DKIM is set up correctly. In the software, go to E-mailings > Extra > DKIM keys to validate the DKIM. You will find the validator in the tab DNS.

Step 3. Validate the DKIM key

You have followed the first two steps precisely. Let’s validate if the DKIM has been configured correctly and can be sent along with your mailings.

  • Go to E-mailings > Extra > DKIM keys.
  • Select your DKIM record.
  • Click to the DNS tab.

Here you will find a list of checks and their results. If there are any errors, solve them before you start sending mails signed with the DKIM.

Warning: Using a wrongly configured DKIM key may harm your sender reputation.

Step 4. Set up a DMARC record

The next step is to set up a DMARC record. DMARC is monitors if an email is signed correctly with DKIM and also checks the SPF record. If these authentications fail it will report this. This is an important check and if it fails it can affect your deliverability.

  • Sign in to the administrator console provided by your domain provider.
  • Locate the page from which you can update the DNS records.

  • Create a TXT record with the name _dmarc.yourdomain.com. (including the underscore) -Paste the following value into the TXT record:

    v=DMARC1;p=none

  • Under E-mailings, go to *Extra > *DKIM Keys and check the DKIM settings. It can take several hours for it to update

It is also possible to set the DMARC record to the following setting:

v=DMARC1;p=reject

However, this means that all email messages from your domain that are not signed with DKIM will be rejected by the receiving mail server. This includes your Outlook or other mail clients emails. So unless you sign all email message with DKIM, it is not recommended to set DMARC to reject all non-signed messages.

Frequently asked questions

My ISP claims that dots and underscores are not allowed in domain names

This is partly true. The use of dots and underscores are forbidden in A and MX records only. There's no problem with using such characters in a TXT record.

Can I create multiple DKIMs under one domain?

Yes, selectors allows a domain to have more than one public key in the DNS. The selector is the first part of the DKIM subdomain. You can for instance have a amsterdam._domainkey.yourdomain.com key and a london._domainkey.yourdomain.com key to distinguish between two affiliates of your organization. If you send bulk mails from different applications, it is highly recommended to use different DKIMs.
